This was exported in large quantity to Japan, China, United States, Europe, Southeast Asia etc..
  This can use to all industrial equipments.
  This is simple equipment.
  This separates load of machine effectively.
  You can use corner angle to prevent fine movement of machine.
  You can order bolt of special specification according to need.
  7 Types : 1.2 ~ 20 ton



▶ LPD Series
Specifications
Inner load weight(kg)
SIZE(mm)
BOLT
Level Adjust.(mm)
LPD-12
1200
123 x 123 x 55
M16 x P2.0
12
LPD-20
2000
180 x 180 x 64
M20 x P2.5
18
LPD-30
3000
236 x 236 x 72
M24 x P3.5
40
LPD-40
4000
326 x 326 x 90
M30 x P3.5
40
LPD-80
8000
435 x 435 x 104
M36 x P4.0
50
LPD-150
15000
451 x 451 x 137
M42 x P4.5
60
LPD-200
20000
487 x 487 x 137
M42 x P4.5
60



* Oil Spray
  Device that spray oil automatically on coil top side or bottom.
* Misfeed detector device
  This protects die by sensing miss feed of coil.


Oil Spray unit

Misfeed Detector
